SPECIFICATIONS |
SIZE OF CORE BARREL (mm) |
|
EWG |
AWG |
BWG |
NWG |
HWG |
|
O.D. of BARREL |
36,50 |
46,00 |
58,00 |
73,00 |
95,00 |
|
I.D. of BARREL |
25,40 |
32,40 |
44,30 |
57,00 |
79,00 |
|
CORE DIAMETER |
21,40 |
30,10 |
42,00 |
54,70 |
76,00 |
|
HOLE DIAMETER |
38,00 |
48,30 |
60,20 |
75,90 |
99,50 |
|
|
|
|
DESCRIPTION |
WEIGHTS |
|
EWG |
AWG |
BWG |
NWG |
HWG |
|
lb. |
kgs. |
lb. |
kgs. |
lb. |
kgs. |
lb. |
kgs. |
lb. |
kgs. |
|
Core Barrel Assembly (3,00m)
(Assembly includes Core Barrel
Head, Tube and Blank Reaming Shell) |
29,99 |
13,60 |
46,97 |
21,30 |
57,33 |
26,00 |
83,79 |
38,00 |
112,46 |
51,00 |
|
Core Barrel Assembly (1,50m)
(Assembly includes Core Barrel
Head, Tube and Blank Reaming Shell) |
14,55 |
6,60 |
22,05 |
10,00 |
30,87 |
14,00 |
44,10 |
20,00 |
63,95 |
29,00 |
|
Tube including Head (3,00m) |
28,89 |
13,10 |
46,31 |
21,00 |
57,33 |
26,00 |
81,59 |
37,00 |
110,25 |
50,00 |
|
Tube including Head (1,50m) |
14,11 |
6,40 |
20,95 |
9,50 |
29,99 |
13,60 |
43,00 |
19,50 |
61,74 |
28,00 |
|
Blank Reaming Shell |
0,44 |
0,20 |
0,88 |
0,40 |
1,32 |
0,60 |
1,76 |
0,80 |
3,09 |
1,40 |
|
Core Lifter |
0,22 |
0,10 |
0,22 |
0,10 |
0,22 |
0,10 |
0,22 |
0,10 |
0,44 |
0,20 |
|
|
